Description
| Specifications | |
|---|---|
| Model | CS-BM1 (1080P) |
| Camera | |
| Image Sensor | 1/2.8” 2-Megapixel Progressive Scan CMOS Sensor |
| Minimum Illumination | 0.1 lux |
| Lens | 4 mm @ F1.6, viewing angle: 100° (Diagonal) , 85° (Horizontal), 46° (Vertical) |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| Night Vision | Up to 5 m / 16 ft |
| Video & Audio | |
| Max Resolution | 1920 x 1080 |
| Frame Rate | 15fps. Self-Adaptive during Network Transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Full HD; Hi-Def; Standard. Adaptive Bit Rate. |
| Audio Bit Rate | Self-adaptive |
| Max. Bitrate | 1 Mbps |
| Function | |
| Detection | Crying Detection, Out-of-Crib (Baby Leaving), Detection Baby Activity (Smart Human) Detection |
| Smart Alarm | Supports |
| Two-way Talk | Supports |
| Auto-play Music | Supports |
| Network | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Minimum Network Requirement | 2 Mbps |
| Storage | |
| Local Storage | Supports microSD card (Up to 256 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay storage (Subscription required) |
| General | |
| Operating Conditions | -10 °C to 45 °C (14 °F to 113 °F ), humidity 95% or less (Non-condensing) |
| Power Supply | DC 5V / 2A （Power adaptor purchased separately) |
| Battery Capacity | 2000 mAh |
| Packaging Dimensions | 225 × 127 × 65 mm (8.86 × 5.00 × 2.56 inch) |
| Dimensions | Rabbit Version: 249 × 50 × 67 mm (9.80 × 1.97 × 2.64 inch) Bear Version: 240 × 50 × 67 mm (9.44 × 1.97 × 2.64 inch) |
| Net Weight | Rabbit Version: 222 g (7.83 oz) Bear Version: 221 g (7.80 oz) |
| Certifications | |
| Certifications | CE / FCC / UL / WEEE / RoHS / REACH / UKCA |
